Pneumatic conveying system design and equipment
We manufacture various types of pneumatic conveying equipment and provide free solution support and itemized quotation references for all users.
Pneumatic conveying system
The working principle of pneumatic conveying system mainly involves the interaction between airflow and materials.
Specifically, the pneumatic conveying system transports materials from the starting point to the endpoint through high-pressure air or compressed air, which can be horizontal, vertical, or inclined. During the transportation process, the material is driven by the airflow and suspended in the pipeline, or forms a group to move along the pipeline. Pneumatic conveying systems can be divided into positive pressure conveying and negative pressure conveying, as well as dilute phase conveying and dense phase conveying. Positive pressure conveying uses high-pressure air to push the material, while negative pressure conveying uses vacuum suction to suck the material into the collection point. Dilute phase conveying is usually used for situations where the conveying distance is short and the material content is low, while dense phase conveying is suitable for long-distance and high concentration material conveying.
In addition, pneumatic conveying systems can also perform physical operations such as heating, cooling, drying, and airflow classification of materials simultaneously during the conveying process, or perform certain chemical operations.
System type
Dilute phase pneumatic conveying system
Dense phase pneumatic conveying system
Device configuration
Feeder
Blower
Parameter setting
Conveying distance and capacity
System pressure
Implementation
Solution design
Installation and commissioning
Training and support
Select Design Preference
We deeply understand the specific needs of customers, select the most suitable type of pneumatic conveying system, and select key equipment and technical parameters.
We Get to Work on Your Vision
Based on the results of customer demand analysis, we conduct detailed design and selection to provide the best solution.
We go in design phase.
After entering the design phase, we carefully plan every detail of the system, including the configuration of fans, feeders, piping systems and control systems.
Let’s Build and Place.
Entering the implementation phase, we provide customers with operation training and technical support to ensure the long-term and stable operation of the system.
